Perlisten Audio R212s Subwoofer
Perlisten Audio R212s Subwoofer
IT'S ALL IN THE DETAILS
Dynamic, Accurate, Solid. The audiophile’s choice. Only upscaled by our D-series subwoofers in output capability but still giving you the same technology and great low frequency extension. Where sound quality and Transients free of overhang are paramount. Simply no better expression of bass performance then our push-pull subs. Ground up drivers developed by our team of engineers. Glass fiber composite diaphragms, multiple aluminum shorting rings, massive magnets, multi-layer Nomex spiders and lightweight aluminum voice coil wire are the key ingredients – Proprietary nonlinear modeling techniques allow us to simulate all these components and then optimize for real world driver performance – free air and in box. Further refinement is done with the aid of Klippel laser measurements to dial things in. To take performance to another level, the push-pull drivers reduce even order harmonics distortion by an additional 10-12dB. Powered by our 1.3kW amplifier, all functions and safeties are controlled by a 48-bit data bath DSP and 32-bit ARM M4 Cortex processor, able to react in microseconds, powerful enough to slam. All R-Series subs share our 2.4” LCD touchscreen display and ability to control advance settings using our App. Certified THX Dominus when 2 R212s subs are used A testament to the level of design and performance achieved.
Specifications
Alignment | Push-Pull, acoustic suspension |
Amplifer | 1.3kW rms short term |
Display Interface | 2.4” LCD color touchscreen |
App | iOS and Android |
Processor | 32-bit ARM Cortex M4, double precision floating point math |
DSP Engine | Ti DSP 48-bit data paths |
Driver compliment | (2)300mm, Glass fiber diaprhragm +/-20mm linear excursion |
Frequency Response | THX EQ 20-256Hz (-6dB) / 16-278Hz (-10dB) Boost (Large Room) EQ 16-256Hz (-6dB) / 14-278Hz (-10dB) Cut (Small Room) EQ 25-256Hz (-6dB) / 19-278Hz (-10dB)) |
Inputs | (2) Balanced XLR (2) Unbalanced RCA |
Outputs | (2) Balanced XLR unbuffered (2) Unbalanced RCA unbuffered |
Parametric EQ | 10-Band PEQ with 3 user presets |
Low Pass filter | Bypass, 30-160Hz, slope 6,12,18,24dB/oct |
Phase | Variable 0-270° |
Polarity | Normal / inverted |
Configurable Auto turn-on and 12v Trigger | XLR 1, XLR 1+2, RCA 1, RCA 1+2 |
Dimensions (HxWxD) | 600 x 410 x 500mm 23.6 x 16.1 x 19.7” |
Weight | 48.2 kg (106.0 lbs.) |
Certification | THX Dominus (2), THX Ultra (1) |
Available finishes | Satin Black |
